SCREEN SERVICE SDT200UB - Table 25. Alarm Thresholds Description

ISO 9001:2000 Cert. N°4500/1
Version 1_2 SDT_ARK6_User_Manual_ENG_v1_2.doc Page 443 of 468
Table 25. Alarm Thresholds Description
altDescr
Threshold Description
Alarm Code
Temp. High -3dB
Temperature alarm threshold expressed in °C.
1
Temp. High Warning
Temperature warning threshold expressed in °C.
2
FWD Pwr Low Warning
Forward power warning threshold expressed in dB.
17
FWD Pwr Low
Forward power alarm threshold expressed in dB.
18
FE Squelch
[DVB-T2] FE Squelch alarm threshold expressed in dB.
1315
FE Pre LDPC BER
[DVB-T2] FE Pre LDPC BER alarm threshold expressed in
dB*1e7.
1316
FE SNR Low
[DVB-T2] FE Signal to Noise alarm threshold expressed in
dB*1e3.
1317
FE MER Low
[DVB-T2] FE MER alarm threshold expressed in dB*1e3.
1318
FE S.Quality Low
[DVB-T2] FE Signal Quality alarm threshold.
1319
Meas Pre LDPC BER
[DVB-T2] Measure Pre LDPC BER alarm threshold
expressed in dB*1e7.
1321
Meas SNR Low
[DVB-T2] Measure Signal to Noise alarm threshold
expressed in dB*1e3.
1322
Meas MER Low
[DVB-T2] Measure MER alarm threshold expressed in
dB*1e3.
1323
Meas S.Quality Low
[DVB-T2] Measure Signal Quality alarm threshold.
1324
FE LDPC Mean Err
[DVB-T2] FE LDPC Mean Error alarm threshold
1330
MEAS LDPC Mean Err
[DVB-T2] Measure LDPC Mean Error alarm threshold
1331
FE Squelch
[DVB-T] FE Squelch alarm threshold.
809
FE Pre Viterbi BER
[DVB-T] FE PreViterbi BER High alarm threshold
(expressed in dB*1e7).
810
FE SNR Low
[DVB-T] FE SNR Low alarm threshold (expressed in
dB*1e3).
811
FE MER Low
[DVB-T] FE MER Low alarm threshold (expressed in
dB*1e3).
812
FE S.Quality Low
[DVB-T] FE Signal Quality Low alarm threshold.
813
Meas Pre Viterbi BER
[DVB-T] MEAS PreViterbi BER High alarm threshold
(expressed in dB*1e7).
815
Meas SNR Low
[DVB-T] MEAS SNR Low alarm threshold (expressed in
dB*1e3).
816
Meas MER Low
[DVB-T] MEAS MER Low alarm threshold (expressed in
dB*1e3).
817
