3. Installation
All unused wires of the TRX control cable must not be twisted or soldered together. All
unused wires have to be insulated seperately avoiding to touch each others.
3.6.1 Connections PTC - KENWOOD
Many KENWOOD radios use a 6 pin DIN socket for remote control. Into some older
transceiver types the serial interface has to be installed previously. Please read the equipment
handbook or consult your dealer.
Signal PTC Color KENWOOD
TxD PIN 9 pink PIN 3
RxD PIN 1 violet PIN 2
CTS PIN 5 blue PIN 5
RTS PIN 10 light blue PIN 4
GND PIN 13 orange PIN 1
Table 12: KENWOOD TTL
Newer Kenwood transceiver (since TS-570) have a 9 pin SUB-D connector and operate with
V24 levels for transceiver control. It´s intended for direct connection to a COM port of a PC.
Also these transceivers can easily be controlled by the PTC-IIpro. Just solder a 9 pin connector
to the attached cable as shown in the table below.
Signal PTC Color KENWOOD
TxD PIN 3 yellow PIN 3
RxD PIN 8 red PIN 2
CTS PIN 4 green PIN 8
RTS PIN 2 white PIN 7
GND PIN 13 orange PIN 5
This cable is available completely assembled.
Refer to chapter 5 on page 52.
Table13: KENWOOD V24
3.6.2 Connections PTC - ICOM
Nearly all ICOM equipment has a 3.5 mm jack socket for remote control. Bi-directional
communication is carried out over a single wire, in order that data can be both sent and
received. Different transceivers have different addresses, so it is possible for more than one
transceiver to be connected to the remote control cable. Further information can be found in the
appropriate literature from ICOM.
Signal PTC Color ICOM
ICOM PIN 6 black inner
GND PIN 13 orange outer
This cable is available completely assembled.
Refer to chapter 5 on page 52.
GND
ICOM-Signal
Figure 5: ICOM plug
Table14: ICOM
44
