Scully Signal Company
3
Applications
TECHNICAL SPECIFICATIONS
Operating Temperature Range
-40°F to +140°F (-40°C to +60°C)
Petroleum Product Range
Gasoline blends and light fuel oils
Exposed Materials
Aluminum, zinc, borosilicate (Pyrex®) glass, epoxy, conductive nylon and Viton® seals
Detection Level and Size
The detection level is adjustable. Refer to Sensor Outline Drawing on previous page, shown for 7” shaft
length. Consult factory for longer sensor length to meet other detection level requirements.
Level Repeatability
0.04 “ (±1 mm)
Electrical Leads
18” (45 cm) long, 18 AWG (0.82mm²)
Cable Entry
Two holes, 1/2” NPT (M20 X 1.5) threads
Approvals
The sensor is intrinsically safe for mounting in Class I, Division 1, Groups C & D Hazardous location in
accordance with Scully Control Unit approval ratings.
