Scully Signal Company
Insallation
4
MECHANICAL INSTALLATION
The sensor is designed to withstand vibrations in road transport. However, the sensor should not be
subjected to any mechanical impact as it may damage the sensor.
MOUNTING LOCATION
The sensor assembly should be mounted in the top of a tank trailer compartment close to the longitudinal
centerline of the tank. In many cases, it is most practical and convenient to mount the sensor holder in
the manlid assembly of the compartment. Many manlid manufacturer's provide a threaded or through-
hole opening for an overfill prevention sensor in the manlid assembly. In choosing a mounting location
other than in the manlid assembly, consider locating the holder in an area where the sensor can be
conveniently reached from the access opening in the manlid assembly. This will greatly simplify any
future maintenance to the sensor.
