SDC Exit Check 101-DE User Manual

P:\INSTALLATION INST\Delayed Egress\INST-101DE_KDE.vsd Rev F 05-16 Page 12
Connecting Optional Accessories
To
Regulated
Power
Supply
REMOTE
BYPASS
PUSH UNTIL ALARM
SOUNDS. DOOR CAN BE
OPENED IN 15 SECONDS.
PUSH UNTIL ALARM
SOUND S. DOOR CAN BE
OPENED IN 15 SECONDS.
TO FIRE COMMAND
CENTER
115 VAC
Door Without Latch Assembly
Activation By Sure Exit Push Bar
R
Power
Supply
Power Transfer
Hinge or Loop
MSB550/PSB560
REX Bar
Lock
Power
RED LED (+)
GRN LED (+)
LED COM (-)
101-1A or
101-1AK
REMOTE
ANNUCIATION
REMOTE
TRIGGER
MSB550,
PSB560
REXTRIG RESET IBO
J4
J6
J1
KEYPAD
RESET
CNO C NO CNO
CNO
CNCNOCNCNO
PWR
LOCK RED RLY GRN RLY
SP1
101-1AK
REMOTE
RESET
Remote Speaker
w/ plug-in
connector
101-SP
EXTERNAL
DPS**
**
Door Contact required for
Anti-Tailgate, BOCA and Door
Prop operation, when a
remote trigger device is used.
Jumper [J6] must be installed
across both pins.
Door Contact is shown with
the door closed.

SDC Exit Check 101-DE Specifications

General

Brand	SDC
Model	Exit Check 101-DE
Category	Controller
Language	English
