Keypad Programming
KEYPAD STATUS LEDS
FACTORY PROGRAMMED CODES
1234
Master Code (default)
11
Reset
22
Authorized Exit (Rex)
Function
Pin
Code
33 Bypass
User
No.
01
02
03
04
Output
Code
NA
2
3
4
*
*
*
*
If the factory programmed codes are acceptable for your
installation, no additional programming is required.
P:\INSTALLATION INST\Delayed Egress\INST-101DE_KDE.vsd Rev F 05-16 Page 8
System Operation
--
POWER-UP LOCKED
The door is
locked and
secure
15
30
or
POWER-UP UNLOCKED
The door is unlocked. To enter the
Armed Mode, turn the keyswitch to
Reset or enter the Reset Code
“11 ” on the keypad
GREEN
Power on, No errors,
No outputs are active
Fast :
Flash
Steady :
No errors,
At least one output is active
RED
General error, invalid code
entered
Steady :
YELLOW
For ADA requirements, it will light
each time a key is pressed
Flash :
Slow :
Flash
Keypad is in Programming Mode
The door is still locked and secure. The display is counting
down with audible alarm/voice instructions. Once the display
reaches “00”, the door will unlock.
15 14 01
DELAYED EGRESS MODE
00
00
The door is unlocked and
has been opened
ALARMED UNLOCKED [Alternating Display]
--
--
--
The door is unlocked and the alarm
is sounding. To return to Armed
Mode, close the door and turn the keyswitch
to Reset or enter the Reset Code “11 “
on the keypad
RESET [Armed] Keypad Code 11 (Green LED solid)
The door is locked and secure
15
30
or
The door is unlocked until the REX timer has expired or
until the door has been opened and then closed.
AUTHORIZED EGRESS [REX] Keypad Code 22 (Green LED Solid)
Door Closed
--
--
--
--
Door has
been opened
BYPASS [Maintained Unlock] Keypad Code 33 (Green LED Flashing)
Door Closed
--
--
--
--
Door has
been opened
The door is unlocked indefinitely. To return to Armed Mode, enter the
Reset Code “11 “on the keypad.
KEY SWITCH BYPASS [Maintained Unlock] (Green LED Solid)
KDE Model Only:
The door is unlocked indefinitely. To return to Armed Mode, close the door and
turn the keyswitch to RESET or enter the Reset Code “11 “ on the keypad.
Door Closed
--
--
--
--
Door has
been opened
