Installation Instructions for the
SK-403/961C Alarm Module with Ant Sensor
Se-Kure Controls,
®
Inc.
3714 Runge Street • Franklin Park, IL 60131 • 1-(800) 322-2435 • (847) 288-1111 • Fax: (847) 288-9999
Rev. 10/24/00 SCI-9677©2000 Se-Kure Controls,
®
Inc.
Step 1: (Removing the Cover)
Fig. 1
Fig. 3
Fig. 2
Remove
the (4)
screws
around
the alarm
module
base.
As shown in Fig. 1 at right, remove the (4) screws
around the base of the Alarm Module. Place the
key in the lock and turn (clockwise) to the “Stand-
By” Position. You can now remove the cover.
Step 2: (Installing 9V Batteries)
As shown in Fig. 2 at right, install (2) 9V Alkaline
batteries, (not included). Push them down until
they snap onto their connectors. Make sure the (+)
positive and (-) negative line up properly.
Step 3: (Replacing the Cover)
Place the cover back on the Alarm Module and
replace the (4) screws you removed to get the
cover off.
Step 4: (Applying Ant Sensors)
• As shown in Fig. 3 at right, remove the backing
sheet from the adhesive and apply it to the sensor.
• Remove the other backing sheet and apply the
sensor to the clean and dry area on the palm.
• Pass the Tie-Wrap thru the slot in the Ant Sensor,
wrap it arount the Palm, and through the tie-wrap
locking mechanism. Cut off excess tie-wrap.
Special Note:
Clean the bottom of sensors and the
area on the product you are going to
apply it with Alcohol Pads.
While still wet, Wipe
the Surfaces
Dry with a clean paper towel or rag.
Tie-Wrap
Palm
Ant
Sensor
SK-909
Ant Sensor
Adhesive
To Next Page
