120
LLHH AACCCCEESSSS CCOOVVEERR
1. To lock, turn the knob 1/4 turn
counterclockwise
FFuussee DDeessccrriippttiioonn
FFuussee
RRaattiinngg DDeessccrriippttiioonn
1 10 A
ECM, Cluster,
Starter Solenoid,
O.T.A.S. (if
equipped) and
CAPS
2 5 A
Engine START/
STOP button
3 15 A
Battery
4 30 A
Charge
5 30 A iBR
*
3 A
Bilge pump (if
equipped)
* The bilge pump fuse is located
above the #1 ACC (10 A) fuse.
1. Bilge pump fuse location (If equipped)
MAINTENANCE PROCEDURES
