Sea-doo Spark Series User Manual

119
NNOOTTIICCEE
DDoo nnoott uussee aa hhiigghheerr rraatteedd ffuussee aass
tthhiiss ccaann ccaauussee sseevveerree ddaammaaggee.. IIff
aa ffuussee hhaass bbuurrnntt oouutt,, tthhee ssoouurrccee ooff
tthhee mmaallffuunnccttiioonn sshhoouulldd bbee ddeetteerr--
mmiinneedd aanndd ccoorrrreecctteedd bbeeffoorree rree--
ssttaarrttiinngg.. SSeeee aann aauutthhoorriizzeedd
SSeeaa--DDoooo ddeeaalleerr ffoorr sseerrvviicciinngg..
FFuussee LLooccaattiioonn
All fuses are located inside a single
fuse box.
To access the fuse box, turn the knob
1/4 turn clockwise, then pull out to un-
snap the rear portion and slide rear-
ward to remove.
LLHH AACCCCEESSSS CCOOVVEERR
1. To unlock, turn the knob 1/4 turn clockwise
The fuse box is located to the left of
the expansion tank.
To remove the fuse box cover,
squeeze and hold locking tabs on both
sides of the fuse box and pull the cov-
er off the fuse box.
1. Fuse box cover
2. Locking tabs
3. Expansion tank
TTYYPPIICCAALL -- FFUUSSEE BBOOXX CCOOVVEERR RREEMMOOVVEEDD
1. Fuse box
NNOOTTEE::
Fuse ratings and positions are illus-
trated on the fuse box cover.
To reinstall the fuse box cover and the
LH access cover, do the reverse of
the removal procedure and lock the
knob by turning it 1/4 turn
counterclockwise.
MAINTENANCE PROCEDURES

Sea-doo Spark Series Specifications

General

Displacement	899 cc
Hull Material	Polytec
Model	Spark, Spark Trixx
Engine Type	Rotax 900 ACE
Horsepower	60 hp / 90 hp
Fuel Type	Gasoline
Fuel Capacity	7.9 US gal (30 L)
Seating Capacity	2 or 3
Length	120 inches (305 cm)
Width	46 in (117 cm)
