FLIPPER
Flipper is an irreversible electromechanical swing gate operator for medium sized piers, maximum leaf length 2 m or 200Kg
weight (see drawing in Fig 4-A)
FLIPPER
230 V (±5%) 50/60 Hz
24V
80 W
-20°C +55°C
8 Kg
200 Kg
2 m
110°
166
266
482
Fig. 1
16
1-Operator 1
2-Operator 2
3-Stop in opening (where
possible)
4-Electronic unit included
5-Flashing lamp +
antenna
6-Photocell Ghost 40
7-Differential switch 16a-
0,03a
8-Key switch Key Plus
9-Column for photocell
Pilar + Ghost40
10-Warning plate
01
1
6
5
6
3
2
4
7
9
9
8
3
Fig. 2
2,
2x 5
5x1
3x1
21x
2 , x1 5 1 x R
G 8+ 5
1,53x
2x1
x3 1
13 x
TECHNICAL DATA
Power Supply
Motor
Power
Working temperature
Weight
Max weight of the gate
Max. weight of the leaf
Opening degrees
DIMENSIONS (mm)
STANDARD INSTALLATION
FITTING AND CONNECTION INSTRUCTIONS
ENGLISH
Sistemi Elettronici
di Apertura Porte e Cancelli
International registered trademark n. 804888
®
REV 02 - 03/2009
