SEA Sprint - Technical Data; Power Supply and Hydraulic Unit; Performance Specifications

13
SPRINT (1 L)
SPRINT (2 L)
SPRINT IV
230V (±5%) 50/60 Hz
220 W
270 W
250 W
220 W
36Vac
12,5 µF 6,3µF
-
-
75%
1430 rpm
-20°C +55°C
130°C
51 Kg
52 Kg
6 m
IP 55
SPRINT FAST SPRINT BR 36V
230V
1 A
1,1 A
1,2 A
12,5 µF
90%
1 L 2 L 3 L
1,5 L
10 s 8 s 3 s
ADJUSTABLE (4 - 10 seconds)
GATE 1 DG UNIGATE FV INVERTER
3
4
5
6
LIGHT -TH
LIGHT -TH
LIGHT -TH
LIGHT -TH
4
5
7
8
GREEN
BLUE
PINK
VIOLET
5
6,5
8
10
16400010R1
16400015R1
16400026R1
16400027R1
6,5
7
8
8,5
ARM
TYPE
MINIMUM
OPENING TIME (s)
SPRING END-ROD
JOINT COLOR
DEFAULT
OPENING TIME (s)
ARM
LENGTH (m)
ARM LENGTH (m)
SPRING WIRE
DIAMETER (mm)
SPRING
CODE
260 W
-
-
UNIGATE BR 36V
2300 rpm
ARMS SPEED CHART (SPRINT IV AND SPRINT BR ONLY)
The usage rate is valid only if all the arm length parameters and the respective speeds are respected;
refer to this table and to those below
Speed setting must respect the minimum value indicated in the «Minimum Opening Time» column
which varies according to the arm length; DO NOT set values lower than the minimum times indicated
TECHNICAL DATA
POWER SUPPLY
HYDRAULIC UNIT
POWER
ABSORPTION
START CAPACITOR
MOTOR ROTATION SPEED
USAGE RATE
OPERATING TEMPERATURE
THERMAL PROTECTION
OPERATOR WEIGHT
OIL TANK CAPACITY
PROTECTION CLASS
OPENING/CLOSING TIME
MAX. ARM LENGTH
ELECTRONIC CONTROL UNIT
SPRING END-ROD JOINT COLOR
SPRING WIRE DIAMETER (mm)
SPRING CODE
SPRINGS FOR «LIGHT-TH» ARMS
2
2,5
3
3,5
4
4,5
5
6
5,5
6,5
6,5
7
7
8
8
8,5
16400005
16400010R1
16400010R1
16400015R1
16400015R1
16400026R1
16400026R1
16400027R1
RED
GREEN
GREEN
BLUE
BLUE
PINK
PINK
VIOLET
In case of FOLDING ARM, set the control unit on 6 meters (menu 11) even if the maximum length of
the folding arm is 4 meters!
The indicated usage rate is valid only for the first operating hour and at a 20°C temperature
