INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 1
90519
1
20 of 29
Section 2: ELECTRICAL INSTALLATION
2.7 ELECTRICAL EQUIPMENT MOUNTING
Precautions:
• Each item of electrical equipment has specific mounting instructions. These instructions
should be followed to ensure proper function of the Seakeeper.
Do NOT move Seakeeper mounted components from their locations or incorrect
Seakeeper operation will result.
1. OPTIONAL: MULTI-FUNCTION DISPLAY INTEGRATION INSTRUCTIONS
a. The following Technical Bulletins outline the instructions for MFD Integration:
i. TB 90478 – GARMIN AND SEAKEEPER COMPATIBILITY
ii. TB 90479 – RAYMARINE AND SEAKEEPER COMPATIBILITY
iii. TB 90479 – SIMRAD AND SEAKEEPER COMPATIBILITY
iv. Additional MFD compatibility will be added as new integrations become available.
Please contact Seakeeper for additional information.
b. Seakeeper MFD compatibility cable part numbers can be found in the relevant technical
bulletin for the specific MFD, listed above.
2. OPTIONAL: CONNECTBOX HELM MOUNTING KIT
a. Console space required: Approx. 3.41 L x 4.15 W inches (87 x 106 mm).
b. Mounting Instructions, Surface Mount: See Drawing No. 90558 for details. Seakeeper
ConnectBox 3D Model available upon request.
c. Mount ConnectBox Replacement Blank insert into Seakeeper 1 enclosure at the original
location of the ConnectBox.
3. OPTIONAL: 5-INCH TOUCH DISPLAY MOUNTING INSTRUCTIONS, SURFACE MOUNT:
a. Console space required: Approx. 5.24 W x 3.70 H inches (133 x 94 mm).
b. Mounting Instructions, Surface Mount: See drawing 90438 for details. Seakeeper Tou
ch
D
isplay 3D Model available upon request.
4. NMEA COMMUNICATIONS TEE ADAPTER AND TERMINATOR MOUNTING INSTRUCTIONS:
a. Space required: Approx. 4 W x 3 H inches (102 x 76 mm).
b. Mounting Instructions: mount on vessel’s existing NMEA Backbone
.
