7. MAINTENANCE
7.1. Before and after each use, check that stands and stand welds are not cracked and that there are no missing or damaged parts, including
fixings. Any suspect stands must be removed from service immediately. An annual inspection of the stand is recommended to be carried
out by an authorised repair facility.
7.2. Periodically lubricate the fine adjuster thread with a light general purpose oil.
7.3. After use, wipe clean the stand and saddles.
Restrain the sprung loaded
tube when removing the varia-
ble height setting pin.
Variable height
setting pin
75mm steps.
Rotate for height
ne adjustment
75mm end stop
to end stop
Safety
Pin
75mm
Fine Adjustment
1295mm Minimum +75mm ne adjustment
1830mm Maximum + 75mm ne adjustment
7 Pitches of 75mm
2a, 2b, 2c
1
4
3
5
7,9,10,11
8,9,10,11
6
7,9,10,11
