• 5 •
4.7 For a positive-grounded vehicle, connect the NEGATIVE (BLACK)
clamp from the jump starter to the NEGATIVE (NEG, N, -)
ungrounded post of the battery. Connect the POSITIVE (RED) clamp
to the vehicle chassis or engine block away from the battery. Do not
connect the clamp to the carburettor, fuel lines or sheet-metal body
parts. Connect to a heavy gauge metal part of the frame or engine
block.
4.8 When nished using the jump starter, remove the clamp from the
vehicle chassis and then remove the clamp from the battery terminal.
Disconnect the clamps from the unit.
5. FEATURES
1. LCD display
2. Display button
3. Smart cable green and red
LEDs
4. ON/OFF switch
5. Micro USB input port
for recharging
6. 3A
input/output USB port
7. Quick Charge™
3.0 USB output port
8. 2.4A USB output port
9. SSL-JC smart cable
with battery clamps
10. Jump start output
socket
11. LED light
Not shown:
12. Micro USB-USB
charging cable
13. Carrying case
