2.8 Vehicle Coverage
The V862 VW/AUDI Code Scanner is specially designed to work
with most Volkswagen and
Audis sold worldwide of 1990 or newer
models. If a VW/AUDI has a 16-pin "OBD-II style" Data Link
Connector (DTC), the code reader will certainly work. If it has an old-
style 2x2 Data Link Connector (DTC), then it depends on whether
there are 4 or 3 wires connecting to the pins. If there are 4 wires, each
connecting a pin, then it will work. If there are only 3 wires, leaving
one pin disconnected, then it will not work.
For VW/AUDI with old-style 2x2 Data Link Connector (DTC), you
need to have a 2x2 cabling adapter which is not included in this
product package.
3. Operating Instructions ons
3.1 VW/AUDI Diagnostics
Reading Codes
CAUTION: Don’t connect or disconnect any test equipment with
ignition on or engine running.
1) Turn the ignition off.
2) Locate the vehicle’s 16-pin Data Link Connector (DLC).
3) Plug the OBDII connector to the vehicle’s DLC.
4) Turn the ignition on. But do not start the engine.
5) Press the Y button. The Main Menu will be observed on the
display.
6) Use the UP/DOWN scroll buttons to select VW/AUDI from the
menu and press the Y button.
