8) Select Read Codes from the Select Function menu and press the
Y button.
Select Function
►1) Read Codes
2) Erase Codes
3) ECU Information
4) Readiness Test
If there are no Diagnostic Trouble Codes present, the display
will indicate “NO CODES ARE STORED IN THE
MODULE!”
● If there are any Diagnostic Trouble Codes present, the DTC
number and its definition will show on the LCD display.
● The sub-code, the communication protocol, the sequence of
the DTC currently being observed and the total number of
codes detected will be observed on the upper right hand
corner of the display.
● When a DTC’s definition covers more than one display
screen, use the Y button, as necessary, to view any additional
information.
If the DTC definition is not available, an advisory message
prompting you to refer to the vehicle service manual will be
observed on the display.
If more than one DTC is found, use the UP/DOWN scroll
buttons, as necessary, until all the codes have been shown up.
