3) If you do not want to proceed with erasing the codes, press the N
button to exit. A message of “command cancelled” will show up.
4) If you do wish to proceed to erase the codes, then press the Y
button.
5) If the codes are cleared successfully, an “ERASE DONE!”
confirmation message will show on the display. Press any button
to return to the previous menus.
6) If the codes are not cleared, then an “ERASE FAILURE!”
message will appear. Press the N button to return to previous
menus.
Viewing ECU Information
1) To view ECU Information, use the UP/DOWN scroll buttons
to select ECU
Information from Select Function menu and
press the Y button.
Erase Codes
Erase Trouble Codes!
Are you sure?
<YES> NO
Select Function
1) Read Code
2) Erase Code
►3) ECU Information
4) Readiness Test
● If the scan tool is not connected or no communication is
established with the vehicle yet, then refer to Reading Codes
from 1 to 7 at Paragraph 3.1.
