Seamax Inflatable Boat – English User Manual
- 13 -
Model
eMarine305 eMarine365 Sport240 Sport270 Sport360 Sport420
Floor Boards
4 5 4 4 5 5
Side Joiners
2 4 2 2 4 4
Model
HD330 HD360 HD380 HD470 AIR270 AIR320
Floor Boards
4 5 5 6 4 4
Side Joiners
4 4 4 4 2 4
Placement of the floorboards
Tips:
• You will notice that the first couple of times you install the floorboards it will be a little difficult this
is normal, After a while it will all go easier because the material will have stretched.
• When you place the floorboards, pull up the fabric a bit to avoid damage to the outside chambers.
• Once inflated a few times the installation of the floor board will be very easy.
Between each floorboard you have to install an inside-joiner. Place the inside-joiners with the broad side up
(See drawing 1, 2). With each boat there are two side-joiners which you have to install on the sides of the
floorboards. These joiners lock the floor in place to become a very stable platform for the boat
