DIVISION 20
BASIC FIELD MANUAL
FOR
MICROWAVE OVEN
MODEL 721.66462500
721.66469500
721.66464500
721.66463500
June, 2005
MODEL 721.66462
721.66469
721.66464
721.66463

Other manuals for Sears 721.66462500

Questions and Answers

  • J
    Jacqueline ParksJul 31, 2025
    What to do if my Sears Microwave Oven produces little heat?
    • K
      Karen WilliamsJul 31, 2025
      If your Sears Microwave Oven seems to be running but isn't heating food properly, it could be due to a decrease in power rating voltage. It is suggested that you contact your local electric power utility company or a qualified electrician. Also, the issue might be with a defective PCB assembly or a defective magnetron, which would need replacement.
  • H
    Helen RiceAug 4, 2025
    Why is my Sears Microwave Oven sparking?
    • C
      Charles ReynoldsAug 4, 2025
      Sparks in your Sears Microwave Oven can occur if you're using metallic ware that touches the oven wall. Avoid using metallic ware for cooking, unless specified in the cooking guide. Also, do not use ceramic ware trimmed with gold or silver powder, as any type of cookware with metallic trimming can cause sparks.
  • P
    patriciafaulknerAug 9, 2025
    Why is the output power of my Sears 721.66462500 Microwave Oven too low?
    • W
      weaverchadAug 10, 2025
      If the output power of your Sears Microwave Oven is too low, it might be due to low AC input voltage. Ensure you are using the microwave oven at adequate line voltage.
  • E
    Erica RomanAug 14, 2025
    What causes no microwave oscillation in a Sears Microwave Oven when the lamp and fan run?
    • A
      Alan ChenAug 15, 2025
      If your Sears Microwave Oven's lamp and fan motor are running, but there's no microwave oscillation, it could be due to several defective components. These include a defective PCB assembly, high voltage capacitor, high voltage transformer, high voltage diode, or magnetron. Each of these would need to be replaced.
  • H
    harriselaineAug 20, 2025
    What to do if Sears Microwave Oven display shows figures but doesn't start?
    • R
      Ricky RiceAug 20, 2025
      If your Sears Microwave Oven's display shows all figures but the oven doesn't start cooking, even when the START pad is touched, there could be a few reasons. This could be due to a defective secondary switch, PCB assembly, fan motor, or oven lamp, any of which would need to be replaced.
  • M
    Megan DavisAug 25, 2025
    How to repair a Sears 721.66462500 Microwave Oven when the display is blank and it won't start?
    • J
      Jason NormanAug 26, 2025
      If your Sears Microwave Oven isn't operating, the display window shows no figures, and no input is accepted, it could be caused by a defective PCB assembly, a defective high voltage capacitor or a defective high voltage transformer. In each case, the defective part should be replaced.

Summary

PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

ADJUSTMENT PROCEDURES

ADJUST THE LATCH AND SWITCH CLOSING

Procedures for adjusting door latches and interlock switches for proper operation and safety.

TEST THE MICROWAVE ENERGY LEAKAGE

Measuring microwave energy leakage to ensure compliance with safety standards.

TRIAL OPERATION

OVERALL CIRCUIT DIAGRAM

OPERATING PROCEDURES

PROCEDURE FOR MEASURING MICROWAVE ENERGY LEAKAGE

CAUTIONS

Safety cautions for service personnel during microwave energy leakage testing.

MEASURING MICROWAVE ENERGY LEAKAGE

Procedure for measuring microwave energy leakage using a survey meter.

MEASUREMENT WITH THE OUTER CASE REMOVED

Instructions for measuring microwave leakage after component replacement with the outer case removed.

MEASUREMENT WITH A FULLY ASSEMBLED OVEN

Procedure for measuring microwave leakage on a fully assembled oven.

POWER OUTPUT MEASUREMENT

Procedure for measuring the microwave oven's power output using a water load.

DISASSEMBLY INSTRUCTIONS

INTERLOCK SYSTEM

Details on the interlock mechanism and switch mounting for microwave safety.

INTERLOCK CONTINUITY TEST

PRIMARY INTERLOCK SWITCH TEST

Procedure to test the primary interlock switch continuity using an ohmmeter.

SECONDARY INTERLOCK SWITCH TEST

Procedure to test the secondary interlock switch continuity using an ohmmeter.

MONITOR SWITCH TEST

Procedure to test the monitor switch continuity using an ohmmeter.

TEST AND CHECKOUT PROCEDURES, AND TROUBLESHOOTING

TEST PROCEDURES

Procedures for testing key components like transformers, magnetrons, capacitors, and relays.

CHECKOUT PROCEDURES

TROUBLE SHOOTING
