1-1
Rated Power Consumption
1700W maximum (Microwave oven+Cook top lamps+Ventilation fan)
Microwave Output 1150W (IEC 60705)
Frequency 2,450 MHz ± 50 MHz
Power Supply 120 VAC, 60 Hz
Rated Current 15.5 Amp. (Microwave oven+Cook top lamps+Ventilation fan)
Magnetron Cooling Forced Air Cooling
Rectification Rectification Voltage Double Half-Wave
Door Sealing Choke System
Safety Devices Magnetron Thermostat: Open at 145 °C ±5 °C
Close at 60 °C ±5 °C
Oven Thermostat: Open at 110 °C ±5 °C
Close at 0 °C ±5 °C
Fuse(20A)
Primary Interlock Switch
Secondary Interlock Switch
Interlock Monitor Switch
Magnetron 2M282J (Toshiba)
Cook top Lamp 120 V, 20 W (Halogen)
Cavity Lamp 120 V, 20 W (Halogen)
Timer Digital, up to 99 min. (in each cooking stage)
Tray Tempered Safety Glass
Overall Dimensions 29
15
/16”(W)x16
7
/16”(H)x15
3
/8”(D)
Oven Cavity Size 23
1
/2”(W)x10”(H)x14
1
/2”(D)
Effective Capacity of Oven Cavity 2.0 Cu.ft.
Accessories Owner ’s Manual & Cooking Guide, Installation Manual,
Exhaust Adapter, Exhaust Damper, Mounting Kit and Filter,
Rotating Ring Assembly, Glass Tray, Metal Rack, Guide Tray.
SWITCH CHART
SPECIFICATIONS
NOTE: Use the above switch chart with circuit diagram on page 5-1.
PRIMARY SECONDARY INTERLOCK
INTERLOCK INTERLOCK MONITOR
SWITCH SWITCH SWITCH
COM COM COM
NO NO NC
OPEN OPEN CLOSE
CLOSE CLOSE OPEN
SWITCH MODE
CONDITIONS
DOOR OPEN
DOOR CLOSED
