Sears SS/16 - air cleaner; cooling system

maintenance
instructions
air cleaner
.CAUTION: If air cleaner becomes too d irty , engine
w il l not rece ive sufficient air to run properly. Symp·
toms: Loss of power, flooding, hard to star t and ~ver-
heating. NUT
PAPER
ELEMENT
POLYURETHANE
PRE-CLEAN ER
HOSE
INTAKE TU BE
FIG. 13
Th i s engine is equ ipped w ith a paper element and o
polyurethane precleaner that must be removed, clean-
ed and oiled ever y 25 hours of operation, or more
under e xtremely dusty conditions.
1. WASH
2. SQUEEZE DRY
3. COAT WITH O IL
4. IN STALL OVER PAPER ELE MENT
FIG. 14
1. To clean pre-cleaner wash in water and detergent
r efe r ri ng to F i gure 14. Remove excess water by
squeezing like a sponge and allow to dry tho -
roughly. Di stribute th ree tablespoons of SAE 30
engine o il evenly around the pre-cleaner. Knead
into and wring excess oil from pre-cleaner.
2. Depending on conditions in which the tractor is
operating, the i nn er paper element should be re-
placed whenever it becomes excessively dirty.
4485R · 23 .4. 73
. 8 .
CAUTION: NEVER RUN THE ENGINE WITH
THE AIR CLEANER REMOVED . DIRT WILL
ENTER THE ENGINE AND SCORE THE CY -
LINDERS.
cooling system
CLEAN OUT
CHAFF AND DIRT .
FIG . 15
COOLING SYSTEM : Ch eck and c lean cooling fins at
leas t eve.; 50 hours . Remove any dust, dirt or oil
wh ic h may h ave accumulated. Remove any ahaff from
1tati ng and sta t ionery b low er sc ree n.
CAUT I ON: Plugged or clogged cooling fins or blower
screens can cause overheating and engine damage.
THIS TRACTOR HAS AN AIR COOLED EN .
GINE. AIR MUST BE ABLE TO CIRCULATE
FREELY
AROUND THE ENGINE, TtiROUGtl
THE SCREEN GUARD AND GUARD (ROTARY
SCREEN), AND OVER THE FINS OF THE
CYLINDER BLOCK. KEEP THESE AREAS
FREE OF ACCUMULATED DIRT AND TRASH
OR THE ENGINE WILL OVERHEAT AND
RESULT IN DAt1 i AGE TO ENGINE..
