Installation Instructions & Owner's Manual
TEMPLATES
REMOVE THIS AREA
FROM THE PANEL
REMOVE THIS AREA
FROM THE PANEL
REMOVE THIS AREA
FROM THE PANEL
REMOVE THIS AREA
FROM THE PANEL
DRILL 7/16" DIA. HOLES
2 PLACES
DRILL 7/16" DIA. HOLES
4 PLACES
LINE INDICATES OUTER EDGE OFCONTROL SENDER
SINGLE HEAD SIDE-BY-SIDE MOUNTING
