Hynautic Hydraulic Engine Controls – 04 Series
TECHNICAL INFORMATION
/iÃiÊ>ÀiÊÌiÊÀiVi`i`Ê>ÝÕÊÌÀµÕiÊÛ>ÕiÃÊvÀÊÀiÕÃ>LiÊ
`ÀÞÊLÌðÊÌÃÊÃÕ`ÊLiÊÌÀµÕi`ÊÌÊÌÃÊÛ>Õiʳä¯ÊÓ䯰ÊÀÊ
ÕLÀV>Ìi`ÊLÌÃ]ÊÕÌ«ÞÊÌiÊ`ÀÞÊLÌÊÌÀµÕiÊÛ>ÕiÃÊLÞÊ°Çx°
Bolt Torque Specifications
Values are stated in: in/lbs (N.m)
Bolt Size 18-8SS Brass
2-56 2.5 (.282) 2.0 (.226)
2-64 3.0 (.338) 2.5 (.282)
3-48 3.9 (.440) 3.2 (.361)
3-56 4.4 (.497) 3.6 (.407)
4-40 5.2 (.587) 4.3 (.486)
4-48 6.6 (.740) 5.4 (.610)
5-40 7.7 (.869) 6.3 (.712)
5-44 9.4 (1.06) 7.7 (.869)
Bolt Size 18-8SS Brass
6-32 9.6 (1.08) 4.9 (.554)
6-40 12.0 (1.35) 9.9 (1.12)
8-32 20.0 (2.25) 16.0 (1.81)
8-36 22.0 (2.48) 18.0 (2.03)
10-24 23.0 (2.59) 19.0 (2.14)
10-32 32.0 (3.61) 26.0 (2.94)
1/4”-20 75.0 (8.47) 62.0 (7.01)
1/4”-28 94.0 (10.6) 77.0 (8.70)
Bolt Size 18-8SS Brass
5/16”-18 132.0 (14.91) 107.0 (12.10)
5/16”-24 142.0 (16.04) 116.0 (13.11)
3/8”-16 236.0 (26.66) 192.0 (21.71)
3/8”-24 259.0 (29.20) 212.0 (23.97)
Values are stated in: ft/lbs (N.m)
Bolt Size 18-8SS Brass
7/16”-14 31.0 (42.00) 26.0 (35.25)
7/16”-20 33.0 (44.74) 27.0 (36.61)
1/2”-13 43.0 (58.30) 35.0 (47.45)
1/2”-20 45.0 (61.01) 37.0 (50.17)
9/16”-12 57.0 (77.28) 47.0 (63.72)
9/16”-18 63.0 (85.42) 51.0 (69.15)
Bolt Size 18-8SS Brass
5/8”-11 93.0 (126.09) 76.0 (103.04)
5/8”-18 104.0 (141.00) 85.0 (115.24)
3/4”-10 128.0 (173.55) 104.0 (141.00)
3/4”-16 124.0 (168.12) 102.0 (138.29)
7/8”-9 194.0 (236.03) 159.0 (215.58)
7/8”-14 193.0 (261.67) 158.0 (214.22)
Bolt Size 18-8SS Brass
1”-8 287.0 (389.12) 235.0 (318.62)
1”-14 259.0 (351.16) 212.0 (287.43)
*i\Ê Èä{Ó{nÎnxn
i>\Ê Ãi>ÃÌ>ÀJÃi>ÃÌ>ÀÃÕÌðV
ÕÀÃ\Ê `>ÞÊÌÊÀ`>ÞÊäx\ääÊqÊ£x\ÎäÊ*-/
7iL\Ê ÜÜÜ°Ãi>ÃÌ>ÀÃÕÌðV
SeaStar Solutions Technical
Support Contacts:
