Installation Instructions and Owner's Manual

WASHER

JACKPLATE ENGINE

BRACKET

OUTBOARD ENGINE

MIDSECTION

NOTE:

ALL HARDWARE TO BE

SUPPLIED OR APPROVED

BY THE OUTBOARD ENGINE

MANUFACTURER

NUT

BOLT

WASHER

Figure 6. Outboard Engine to Jackplate connection.
