Fuses and bulbs
No. Consumers/Amps
23 Electric sunroof 30
24 Right lights 40
25 Left door 30
26 Heated seats 30
27 Interior light 30
28 Trailer 25
32
Control unit for parking aid, front
camera and radar
7.5/10
33 Airbag 5
34
Reverse switch, climate sensor,
electrochromic mirror, rear power
sockets (USB)
7.5
35
Diagnosis, headlight control unit,
headlight adjuster
10
36 Right LED headlight 7.5
37 Left LED headlight 7.5
38 Trailer 25
39 Right door 30
40 12V socket 20
42 Central locking 40
43
SEAT Sound, beats sound CAN
and MOST.
30
44 Trailer 15
No. Consumers/Amps
45 Electric driver's seat 15
47 Rear window wiper 15
49 Starter motor; clutch sensor 5
50 Electric rear lid 40
52 Driving mode. 15
53 Heated rear window 30
Fuse arrangement in engine compartment
No. Consumers/Amps
1 ESP control unit 25
2 ESP control unit 40
3
Engine control unit (diesel/pet-
rol)
30/15
4 Engine sensors 5/10
5 Engine sensors 7.5
6 Brake light sensor 5
7 Engine power supply 10
8 Lambda probe 10/15
9 Engine 5/10/20
10 Fuel pump control unit 15/20
11 PTC 40
12 PTC 40
No. Consumers/Amps
13 Automatic gearbox control unit 15/30
14 Heated windscreen 40
15 Horn 15
16 Petrol pump 5/15/20
17 Engine control unit 7.5
18 Terminal 30 (positive reference) 5
19 Front windscreen washer 30
20 Alarm horn 10
22 Engine control unit 5
23 Starter motor 30
24 PTC 40
31 Pressure pump 15
33 Gearbox pump 30
37 Parking heating 20
Note
●
In the vehic
le, there are more fuses than
those indicated in this chapter. These should
only be changed by a specialised workshop.
●
Positions not containing a fuse do not ap-
pear in the following tables.
●
Some of the equipment listed in the tables
below pertain only to certain versions of the
model or are optional extras.
»
