260 If and when
– Remove the connector ⇒ fig. 165
2
from the bulb.
– Unclip the retainer spring ⇒ fig. 165
3
pressing inwards to the
right.
– Extract the bulb and fit the replacement so that the rim of the
attachment plate is on the reflector cut-out.
Main beam lights
Fig. 166 Main beam
headlights
Fig. 167 Main beam
headlights
– Raise the bonnet
– Remove the cover ⇒ fig. 166
C
by pulling on this.
– Remove the connector ⇒ fig. 167
1
from the bulb.
– Press the spring ⇒ fig. 167
2
inwards and to the right.
– Extract the bulb and fit the replacement so that it sits correctly
into the cut-out on the reflector.
– Installation is done in the reverse order.
