Emergencies
No. Consumers/Amps
12 Right lights 40
13 Central locking 40
14 Beats Audio CAN and MOST. 30
16 Airbag 7.5
17 SCR, engine relay, 1.5 10/15
18 KESSY 10
19 Instrument panel 7.5
20 Connectivity Box 7.5
21 Rear camera 7.5
24 4x4 Haldex Control Unit 15
26 Right door 30
29 Trailer 15
30 Radio 20
31 Trailer 25
35 Left lights 40
36 Air conditioner fan 40
37 Electric rear lid 30
39 Heated steering wheel 10
40 Alarm horn 7.5
41 Gateway 7.5
42 Automatic gearbox lever 7.5
No. Consumers/Amps
43
Air conditioning and heating con-
trol panel, r
ear window heating, AA
compressor
10
44
Diagnosis, handbrake switch, light
switch, r
everse light, interior light-
ing, lit-up door sill
7.5
45 Steering column 7.5
46 Radio display 7.5
47 Driving mode. 15
48 USB 7.5
52 12V socket 20
58
Parking sensors, parking assist
contr
ol unit, front camer
a, radar
7.5
59
Reverse switch, clima sensor, elec-
trochromic mirror
7.5
60
Diagnosis, headlight control unit,
headlight adjuster
7.5
61 Starter motor; clutch sensor 7.5
64 Airbag 7.5
65 Sound amplifier 10
66 Rear window wiper 15
67 Heated rear window 30
Fuse arrangement in engine compartment
No. Consumers/Amps
2 Engine control unit 7.5
3 Fuel pump control unit 7.5
7 Automatic gearbox pump 30
9 Horn 15
10 Front windscreen washer 30
12 Automatic gearbox control unit 15/30
13 ESP control unit 25
15 ESP control unit 40/60
17 PTC 40
18 PTC 40
20 Front electronic differential 15
21 Engine control unit 5
22 Starter motor 30
23 Engine control unit (diesel/petrol) 30/15
24 Engine sensors 7.5/10
25 Engine sensors 7.5/10
26 Engine power supply 7.5/10
27 Lambda probe 10/15
28 Engine 10/20
29 Fuel pump control unit 15/20
