Sebo 300 - Dust Bag Housing and Handle Schematic

5
2
3
3
4
3
7
9
10
12
19
P
U
S
H
X
5
0
1
5
0
13
11
8
20
19
2831
19
14
6
3
32
1
1
1
1
29
20
19
18
30
3433
23
22
21
24
25
19
26
19
27
19
19
19
19
15
16 17
35
36
13
MECHANICAL SCHEMATIC AND PARTS LIST
#
91303AM, #91313AM
P
os. Part # Description
1 50100SE Dust bag housing cpl.
2
50145SE Handle tube incl. tube cover
3 0127 Screw M4 x 10k, taptite
4 50147ER Clamp
5 50153HGER Handle cpl.
6 0104 Screw C3.9 x 25 DIN 7981
7 50200GS Dust bag housing
8 50165HG Extension tube
9
50105HG Connection tube
10 0107 Screw C2.9 x 13
1
1 501843 Cable w/US-plug (gray-black) 13m
12 50118HG Dust bag housing bumper base
13 5040SB Hose cpl. X (silver)
14 50205ER Filter safety catch cpl.
15 50122OR Dust bag lever
1
6 50123ER Axle
17 50124ER Return spring
1
8 50125ER Bag holder
19 01036 Screw 4 x 14
20 2014 Axle clamp
21 50209ER Filter indicator
22 5424GS1 Retaining ring
2
3 50130HG Recessed grip
24 50131HG Fitting
2
5 5289 Seal
26 50142ER Anti-static wire
27 50143GSER Carry handle
28 50216OR Box exhaust filter
29 50215GS Back cover
30 50170ER Exhaust filter
31 5036ER Micro hygiene filter
32 5093AM Dust bag
33 1092JE Crevice nozzle (lt. gray)
34 1491JE Upholstery nozzle
35 1387GS Dusting brush
36 1081GS Mounting clip w/screw
Dust Bag Housing and Handle
