P/N VT-108731-IE, Manual revision: B
Label for OMNI™ Power Source, depicts the serial plate. Each unit's serial plate
(located on the rear of the unit) indicates the model number and serial number of
the unit. Refer to the serial number when contacting Vante
®
Customer
Care
Center.
Serial Tag
Power Switch
Fuse Holder
RF Power
Output
DC Output
Power Input
Receptacle
Figure 2-3, OMNI
™
Power Source Power Interface Panel
Figure 2-4, Serial Plate Label for OMNI
™
Power Source
Caution:
Unit equipped with dual fuses. Disconnect power cord before replacing
fuses.
