Modell 869 25
G
Changing the batteries
When or bAtt appear in the display, you should change the batteries. You need
6 type AA 1.5 V batteries.
– Carefully turn over the scale so that the
base of the scale is accessible.
– Open the cover.
– Insert the new batteries in the battery
compartment.
Check that the polarity is correct!
–Close the cover.
– Then turn the scale back up the right
way.
8. Technical data
Dimensions scale
width: 313 mm
height: 60-66 mm
depth: 315 mm
Dimensions weighing platform
width: 205 mm
height: 55 – 75 mm
depth: 48 – 80 mm
Height of figures 20 mm
Weight approx. 4,3 kg
Temperature range +10 °C to +40 °C
Maximum load 250 kg / 550 lbs / 39 sts
Minimum load 2 kg / 4.4 lbs
Power supply Battery/
mains unit (option)
Power consumption approx. 30 mA
Batteries 6 type AA 1.5 V batteries
EN 60 601-1:
Insulated equipment,
Protection Class II:
medical electrical equipment type B:
Accuracy greater than ± 0,15 %
