2
2.1 Carton Inventory
3. INSTALLATION
Remove the back cover from the unit
Drill 2 holes (A,C) on the wall for the screws and one hole for the cable
Knock the supplied rubber bungs to the screw holes(A,C)
Fix the back cover firmly on the wall with 4 flat head screws
Thread the cable through the cable hole (B)
Attach the unit to the back cover
Physical
Colour
Dimensions
Unit Weight
Shipping Weight
ABS Shell
Black (White, optional)
L103* W48 * H20 (mm)
100g
150g
