Secure H3747 - Upgrading and Installing the PTD; Channel Plus Upgrade and Commissioning

Product technical specifications
Receiver H3747
Operating temperature 0°C to 40°C
Pollution degree 2
Ingress protection IP30
Rated input voltage 230V ± 10% AC
Relay contact voltage rating,
Ch1 to Ch4
Volt free (max 230/240 V AC)
Relay current rating 3(1) A maximum
Relative humidity 0% to 95% non condensing
Storage temp. range
-20°C to +70°C
Wireless communication
WiFi (2.4 GHz) , 2.4 GHz RF
1. Safety : Class II as per BS EN 60730-1;
EN 60730-2-7; EN 60730-2-9
2. EN 301 489-1,17
3. EN 300-328
4. RoHS & REACH
5. WEEE
Standards
31
