2. Technical Parameters
Items Specifications
Input Voltage
24VAC (±20%), 50/60HZ
Power Supply to Camera 12VDC
Power ≤35W
Communication RS-485
Baud Rates 2400/S, 4800/s, 9600/s Optional
Pan Speed Horizontal: 12°/Second, Vertical: 12°/Second
Pan / Tilt Angles Horizontal: 0~356°, Vertical: 0~90°
Range Horizontal, Vertical Adjustable
Housing
Upper Cover: High-intensity Flame Retardant ABS
Lower Cover: Acrylic
Working Temperature Outdoor：-20~50℃
Auto Temperature Control
Heater ON：＜41 Degrees F， OFF：≥ 41 Degrees F
Fan ON：＞104 Degrees F，OFF：≤ 104 Degrees F
Max. Dimensions of
Camera and Lens (mm)
115×70×75
3. Protocol Selection
The communication protocol of the decoder is Pelco-P or Pelco D. (Automatically
adjusts).
