6-6 ATTACHING THE ROOF
1
 SupporttheRoofassembledin"6-5"with4ormorepeopleandplaceitonJointFrameL&R.
Payattentiontothefollowingitems:
①PleaseconrmthepositionsothattheRoofBoxisonthesideoftheSeatCabinet.
②Pleaseputitfromthesideagainstthecabinet.
③PlacetheroofonceontheJointFrame.
④Twopeoplemoveontopofthestep.Pleaseplaceitwhilesendingtheroof.
⑤PleaseputtheguideoftheroofbetweentheJointFrame.
⑥PleasemovesothattheguideoftheRoofhitstheSeatCabinet.
Carryoutthisoperationwith4ormorepeople.
JointFrame
JointFrame
JointFrame
Step
RearCabinet
RoofBox
Roof
