NOTE: If the GNSS antenna is blocked, which results in poor signal and inaccurate positioning, please purchase the antenna
extension kit and install as instructed.
Bottom view
Drainage outlet: If the mower falls into water, take it out immediately and put the mower right side up to drain it. Never submerge
the mower in water, otherwise, the components may be damaged and the Limited Warranty will be voided.
Charging station and the GNSS antenna
Blade disc
Blade
Rear wheel/Hub motor
Blade fender
Battery compartment
Front wheel
Drainage outlet
Power interface
Perimeter wire interface
GNSS antenna
LED indicator
Contact strip
Antenna interface
