3
Cal. 7N32C, 7N33C, 7N39C
PARTS CATALOGUE
Remarks:
11 Hour wheel
18 Fourth wheel and pinion
33 Center wheel and pinion
36 Main plate
• Discrimination of the hand installation heights
Cal. 7N Series watches have numerals printed on the dial and the movement to indicate the hand
installation heights. When repairing, refer to the table below.
Discrimi-
nation
Printed on Dial Movement
Numeral for
discrimination
Height Short type
1
Standard type
2
Ex) Standard type
Ex) Standard type
Printed position
The numeral is printed at
the right end.
The numeral is printed
below the calibre number.
Combination:
* The hand installation heights can be discerned from the shape of the following parts. Refer to the table
below.
[Cal. 7N32C]
Numeral for
discrimination
1
2
Center wheel
and pinion
0271 929
Hour wheel
0221 904 0241 904 0271 942 0100 942
Main plate
(Center pipe)
Fourth wheel
and pinion
0100 941
0241 929
0221 929
JAPAN 7N33-5A00 R2
