PARTS CATALOGUE
Cal. H024A
2/7
● For the part 6, please see the remarks on the following pages.
Disassembling procedures Figs. :
Reassembling procedures Figs. :
Lubricating : Types of oil Oil quantity
Moebius A
Moebius F
Silicone Oil 500,000 c.s.
Normal quantity
* Do not disassemble the
buttons except when
they need to be replaced.
Case back
Case back gasket
Movement
Hour, and
minute
hands
Dial
Button spring clip
Piezoelectric element
Button D
Button C
Button B
Button A
6
7
1
2
4
5
Dial ring
Case ring
3
1
1
ed
ed
(AO-3)
(AO-2)
