Seiko LTP1245R-C384-E - Heat Element Dimensions

3-3
3.2 HEAT ELEMENT DIMENSIONS
The LTP1245 contains a thermal head with 384 heat elements (dot-size).
Figure 3-1 Heat Element Dimensions
Figure 3-2 Print Area
48 mm (384 DOTS)
0.125 mm 0.125 mm
58 mm (PAPER WIDTH)
48 mm (PRINTING WIDTH)
5 mm
0.125 mm
(PAPER
FEED
PITCH)
5 mm
0
-1
