CONNECTING EXTERNAL CIRCUITS
The LTP1245 has two types of connectors to connect it to the external circuits: FPC (Flexible Printed
Cable) type connector and FFC (Flexible Flat Cable) type connector.
Table 4-1 shows the recommended connectors.
Table 4-1 Recommended Connectors
No. External Circuit
Functions
Number of
Pins
Recommended Connectors
(External Circuit side)
1
Thermal head control
20
Molex Co., Ltd.
52044-2045 (horizontal type)
52045-2045 (vertical type)
5597-20APB7F (horizontal type)
5597-20CPB7F (vertical type)
2
Motor control, paper
detection, and head-up
detection
9
Molex Co., Ltd.
52030-0919 (vertical type)
52089-0929 (horizontal type)
