DESCRIPTION OF CONTROLS
LEGEND
A Switches for setting the comfort/economy mode:
Interval 0 .. 5
Interval 6 .. 6.30
Interval 9 .. 10
B Manual button
C On/off button
D Time/temperature/programming button
E Comfort knob
F Economy knob
G Forward button
H Back button
I OK button
L Reset button
M Battery holder
N Screws holes for xing the programmable thermostat
body to the wall mount plate
Fig. 5
