Date Code 20000525 SEL-2600 RTD Module
SEL-2030 Communications Processor Applications
7
Figure 2 Motor Protection with the SEL-501 Relay.
Figure 3 Generator Protection with the SEL-300G Relay.
Figure 4 Transformer Protection with the SEL-587 or SEL-387 Relay.
SCADA
EIA-232
PC/HMI
SEL-2800
Fiber-Optic Transceiver
SEL-2030
Communications Processor
SEL-501 Relay
SEL-2600
RTD Module
Motor Load
EIA-232
SCADA PC/HMI
SEL-2800
Fiber-Optic Transceiver
SEL-2030
Communications Processor
SEL-300G Relay
SEL-2600
RTD Module
Generator
Prime
Mover
Transformer
SCADA
EIA-232
PC/HMI
SEL-2800
Fiber-Optic Transceiver
SEL-2030
Communications Processor
SEL-587/387 Relay
SEL-2600
RTD Module
