Page 13
LIBRARY RESET
This will erase all the names and tempos given to the presets. While editing your setlst, hold down the Preset/Edit knob,
Tempo/Save knob and Footswitch for 7 seconds until the screen reads "Library Reset". Wait until the screen switches
back to Live Mode.
FACTORY RESET
While in the Global Menu, hold down the Preset/Edit knob, Tempo/Save Knob and Footswitch for 7 seconds until it
reads "Factory Reset". Release all 3 and wait until the screen switches back to Live Mode. This will take some time so
please be patient while it reads “Factory Reset”. All user data will be erased and restored to factory settings.
CONNECTING TO COMPUTER
Some features and options can only be accessed and changed from a computer (Windows 7/8/10, MAC OS X). The
software allows you to save your session for backing up or sharing. The session holds all the information that is stored on
your pedal. To transfer information to a new Quartz you will have to save the session to your computer from the old one,
and upload that session to the new one.
LEGACY QUARTZ V2 INFORMAION:
The first batch of Quartz V2s have a slightly different circuit to the current model. To tell which version you have, notice
what colour the “QUARTZ” text is when powering on the pedal. If it is Black it is the old version, if it is Blue it is the latest
version. Here are the differences:
a) You can only plug in one extra footswitch (instead of 6 on the latest version. This input is on Jack 3 on the Tip).
b) The old version has a smaller screen.
c) There are also switches inside the pedal that allow for brightness control. The latest version does not have any
way to control the brightness of the screen. The brightness affects how much current the pedal draws from your
power supply. The brighter the screen, the more current the pedal will draw. You may change these switches
while the pedal is powered so you can see the difference in brightness. The current draw for each option is as
follows:
Top Switch: LEFT, Bottom Switch: LEFT = 150mA
Top Switch: LEFT, Bottom Switch: RIGHT= 248mA
Top Switch: RIGHT, Bottom Switch: LEFT = 140mA
Top Switch: RIGHT, Bottom Switch: RIGHT= 192mA
d) Syncing with Diamond pedals is not supported. On the newer version there is an option to modify the pedal so that
output 4 is capable of syncing with Diamond pedals
CAUTION:
FIRST UNPLUG ALL POWER SOURCES TO THE PEDAL BEFORE CONNECTING IT TO THE COMPUTER.
NOW PLUG THE PEDAL INTO THE PC VIA THE USB PORT. THEN OPEN THE SOFTWARE (PEDAL MUST BE
PLUGGED IN VIA USB BEFORE OPENING THE SOFTWARE). IF THE PEDAL CANNOT CONNECT, PLEASE VIEW
THE QUARTZ SUPPORT PAGE ON OUR WEBSITE
