Auto-calibration of the adjuster
In order to assure correct operation of the control system (adjusted to the slip of the head after
stopping the engine), use the auto-calibration function after the first start-up. Use this
function also if the screws of the head's drive or the engine have been replaced or after
applying lubricant to screws or other moving parts of the head, if there are significant
divergences in cutting dimensions. To auto-calibrate, set the saws to the smallest dimension
(smallest spacing of the saws), then switch on the control system, wait until the “ANP-05”
message disappears from the display, then press and hold the “Calibr” button. The
display will show the message: “Auto call”. The control system is ready to auto-calibrate.
Press again the “Calibr” button. The adjuster will perform automatic measuring movements.
After performing measuring movements, the adjuster will indicate the end of the function and
enter normal working mode. During auto-calibration, the adjuster makes a test run over a
distance of approx. 140 mm in the direction of increasing the dimension: it should be taken
into consideration when setting the starting position of the saws.
Having completed the steps above, the adjuster is ready for normal operation.
Operation of the ANP-05 adjuster
Immediately after turning on the power, a red LED will be blinking next to message:
“Check real size”, reminding to check the dimension displayed in the “Real size”
window with the actual dimensions of the saws. In the event of divergences, enter correct
dimensions, following the instructions described in Section 8.
The adjuster allows manual control of the spacing (dimension cut) of the saws using green
buttons with arrows or automatically by entering the dimension and pressing shortly “Start
position”. Enter the dimensions using the numeric keypad or fast dimension buttons described
as “A” to “E”, which are assigned to individual spacing dimensions of the saws. Dimension
values assigned to the keys A-E can be adapted to individual needs, according to the
following description:
In order to change one or more dimensions assigned to the keys A-E, press and hold for
approx. 3s the button “Set Abcde”; after a while the upper display will show the message:
“Abc” and the lower display will show horizontal lines. Now select the key you want to
underwrite with new dimensions and press it shortly. The upper display will show the letter
corresponding to the key which had been pressed and the lower display will show the
previously assigned dimension. Using the numeric keypad, you can enter another value. After
entering the value, press shortly another key with the letter to change the assigned value. After
making all the necessary changes to one or more keys (A-E), save changes by pressing shortly
the button “Save”; the adjuster displays the message: “Save”, confirming the setting. From
now on, the saved dimensions will be available by pressing A-E keys.
List of errors which may occur during the operation of the adjuster:
If an error occurs during operation, the adjuster displays an error message and stops
movement. To erase the message, press shortly the button “Start position” and then
locate the cause of the malfunction and correct it before restarting work.
No power supply:
- check connections of the TSS8/001 transformer.
