Point 7
Checking the values of the input divider
During the display of the “ANP-05” message, press and hold the “Calibr” button; after a
while, the top display will show horizontal bars and the lower display will show the symbol of
the divider (reversed T) and its current value. In case of using the magnetic tape and the
MSK-320 sensor, the divider's value should be 5. Otherwise, enter the correct value of 5 using
the numeric keypad of the adjuster. To save the entered divider value, press shortly the
“Save” button; the message “Save” will appear to confirms correct setting. Enter the divider
value at the first start-up or if there is a suspicion of incorrect configuration of the adjuster.
Point 8
Entering the dimension calibrating the “Real size” counter (Real size)
Warning! Due to the mode of entering the Real size dimension (value to one decimal
place), entering the dimension is possible only if the value shown in the “Real size”
display does not exceed 999mm!!
Due to the one way motion of backlash elimination, be sure to reduce dimension before
entering the dimension (press and hold the button with arrows pointing inwards)!!
To make sure that the top display shows the real size correctly, press the button with arrows
pointing outwards, to set spacing of the saws to any dimension less than 999 mm. Then read
the actual spacing of the saws in the machine, by using e.g. a mechanical gauge of the
machine (if it is precisely calibrated) or by measuring the spacing with another gauge. Then
press and hold for approx. 3s the “Set Real size” button; after a while, the top display will
show horizontal lines and the lower display will show the previously used dimension; using
the numeric keypad, enter the measured spacing value, making sure to enter the dimension
to one decimal place, e.g. the spacing of the saws equal 140 mm should be entered by
pressing: 1, 4, 0, 0, while another sample dimension 232.4 should be entered by pressing: 2, 3,
2, 4. After entering the dimension, confirm by pressing “Save”. The control system will
display the message “Save” and exit the function, while the top display will show the entered
real dimension of the spacing of saws. If the machine has not been mechanically reset while
the power supply of the control system was off, there is no need to calibrate the counter after
restarting (the counter’s dimension is saved in the memory of the control system);
recalibration should be made if the values displayed are divergent or if there was e.g. a
break in the power supply during operation and the control system has not saved the
counter value.
Entering the real value of the spacing of saws is necessary for the correct operation of
the control system!
