Selec PID330 User Manual

16
3. LEVEL 0 - INPUT PARAMETERS
Display
Name & Description
Range
Display
condition
Default
value
Select input type as
Signal Inputs: Linear mV (-5 to
56mV), Voltage (0 to 10V),
Current (4 to 20mA).
RTD: PT100
Thermocouples: J,K,T,R,S,C,E,
B,N,L,U,W. Platinel II.
Input type
Refer table on page 6 for input
ranges.
Resolution
Temperature unit
Feed the value of the display
required at the lower value of
analog input
#1
Display value scaling point1
Feed the lower value of the
analog input signal.
Input value scaling point1
#1
Display value scaling point2
Feed the value of display
required at the higher value of
analog input
Not prompted
for R, S, and
B type
thermocouple
.
TC/RTD
inputs.
Analog input.
Analog input. As per
input type
selected.
Analog input.
PROGRAMMING OF LEVELS
o
Fixed 1 C resolution for R, S, B type thermocouple.
TC * / RTD:
/
Analog
input: / /
/
to
Display
value
scaling
point2
/ V to
Input value
scaling
point 2
mV
mA /
Display
value
scaling
point 1 to
*
/
