TEC Series v 3.2X
Page 37
The RS-232 Baud refers to
the rate of speed for serial
communications, such as a printer or terminal would need. This
function requires the optional printer interface (OPTKPRT). The
different rates are:
0 = 300 BAUD
1 = 600 BAUD
2 = 1200 BAUD
Protocol for serial devices is fixed 3 = 2400 BAUD
at 8 bits, No parity, 1 stop bit. 4 = 4800 BAUD
(8,N,1) 5 = 9600 BAUD
6 = 19200 BAUD
To change the RS-232 Baud from the factory default of 5, press "2" from the
Communications Setup menu to get this sub-menu. Next, select the number corresponding
to the desired baud, and press "*". This will return you to the Communications Setup menu.
The Site Code (sometimes called a Facility
Code) is used with the Card Readers. Site Code is used to
identify the group of cards being used with a particular TEC. This
keeps cards on one facility from being used in another facility.
The range of Site Codes is from 000 - 255. 000 = OFF (NO CARDS ARE IN USE)
To change the Site Code from the factory default of 000, press "5" from the Communications
Setup menu to get to this sub-menu. Key in the desired 3 digits corresponding to the Site Code of the
cards you have purchased, and press "*".
NOTE: IF SITE CODE = "000" THE CARD READER FUNCTION IS DISABLED, AND CARD
# WILL NOT APPEAR IN CODE/NAMES PROGRAMMING MENU . IF SITE CODE IS SET TO 255,
THE SITE CODE ON THE CARD WILL BE IGNORED, AND SECURITY OF CARDS WILL BE
REDUCED.
The TEC leaves the factory
with a default password of 777777. The Password may be
alphanumeric (1 - 6 characters) if programmed from an optional
terminal. From the front keypad, only numbers (1 - 6 digits) are
supported. This provides an additional level of security if you connect a terminal to a TEC. It is
possible to create passwords that can not be accessed from the front keypad. To change the
Program Password from the factory default of 777777, press "3" from the Communications Setup
menu to get this sub-menu. Key in the desired 6 digits for the new password, and press "*". You will
be returned to the Communications Setup menu.
SITE CODE
SITE CODE = 000
PASSWORD =
777777
PROGRAM PASSWORD
This function determines which
door control relay is activated when a
PIN code (or a Rotary "6" from a called unit) is received by the
TEC. To change the number from the default setting of 1 to
another number, select "4" from the main menu. Select "4" from this sub-menu. Select the new
number (from 1 - 4) and press "*". You will be returned to the COMM. SETUP menu.
PIN ON ENT = 1
PIN ON ENTRANCE
NOTE: 1
st
2 DIGITS OF PROGRAM PASSWORD ARE THE CONTROL PASSWORD,
FOR REMOTE CONTROL OF TEC UNIT (SUCH AS ENTRANCE LATCH). 1
st
3
DIGITS OF PROGRAM PASSWORD ARE THE MANAGERS PASSWORD THAT
ALLOWS ONLY CODE, NAME, PHONE, PIN, CARD, AND GROUP CHANGES.
RS-232 BAUD
RS-232 BAUD = 5
