TEC Series v 3.2X
Page 45
Press "7" from the main menu to get the selection shown at
right. Press “*” to return to the Main menu
AL1 (USES TIME ZONE 1
MORNING HOURS M - F)
TRANSACTION BUFFER INFORMATION
EXAMPLE OF AN AUTOMATIC UNLOCK APPLICATION
BUFFER INFO.
SELECT 1 - 5
The transaction buffer stores any event that would normally create a logging printer message. For
examples of report messages, see Pg. 18 or 66. The size of the transaction buffer depends on the
capacity of the TEC. Usually, the smaller the capacity the larger the transaction buffer space. After a
transaction buffer becomes full, it begins to overwrite the oldest event in the transaction buffer storage
space.
Time Zone Setting
Start Time Stop Time Day of the Wee
Time Hour Min.
Hour
Min.
0
1
07 45
08
15
X X X X X
2
16 45 17 15
X X X X X
ENTRANCE
ACCES TIME
0
1 1 X X
2 2 X X
AL2 (USES TIME ZONE 2
AFTERNOON HOURS M - F)
Access Level Setting
Access Levels
ACCESS
0
1 X X
2
Always Active Always Active
AG1 (USES ACCESS LEVELS 1 AND 2 )
THEN USE AG1 TO AUTO UNLOCK
ENTR. 1 AND ENTR. 2
These are shorter versions of the other tables in this manual. Start by defining which entrance
is to be unlocked, for how long, on which days. This is the time zone data. Next, define which
combinations of doors are controlled by a time zone. This is an access level. Last, group access
levels into an access group. The Entrance Group is that access group number.
SETUP AND PROGRAMMING
