TEC Series v 3.2X
Page 66
Press "7" then “1” from the main menu to get the selections shown below. View Log will display the
Log one page at a time. Press “0” to stop and then “Enter” key to return to the Main menu
TRANSACTION BUFFER INFORMATION
EXAMPLE OF AN AUTOMATIC UNLOCK APPLICATION...Continued...
The transaction buffer stores any event that would normally create a logging printer message. For
examples of report messages, see below. The size of the transaction buffer depends on the capacity
of the TEC. Usually, the smaller the capacity the larger the transaction buffer space. After a
transaction buffer becomes full, it begins to overwrite the oldest event in the transaction buffer storage
space.
Access Levels
ACCESS
0
1 X X
2
Always Active Always Active
AG1 (USES ACCESS LEVELS 1 AND 2 )
THEN USE AG1 TO AUTO UNLOCK ENTR. 1 AND
ENTR. 2
These are shorter versions of the other tables in this manual. Start by defining which
entrance is to be unlocked, for how long, on which days. This is the time zone data. Next, define
which combinations of doors are controlled by a time zone. This is an access level. Last, group
access levels into an access group. The Entrance Group is that access group number.
Pressing "2" will send all logging data. This allows the log
to be viewed from start to finish from the terminal. The log
will be shown non-stop .
CAUTION: No entry is accepted until the complete log is
sent.
SEND LOG
VIEW LOG
SETUP AND PROGRAMMING
(CAT Shown. TEC is similar.)
