MANUAL DE INSTRUCCIONES CODIGO 80104 REV J 02/2021 Pag.: 9
J.P. SELECTA s.a.u. Autovía A-2 Km 585.1 Abrera 08630 (Barcelona) España Tel (34) 93 770 08 77 Fax (34) 93 770 23 62
e-mail: selecta@jpselecta.es - http://www.grupo-selecta.com
TECHNICAL FEATURES
Voltage supply 115-230V 50/60 Hz according to the
characteristics plate indications.
Code
Cap.
litres
No.
shelves
Internal dimensions cm Overall dimensions cm
Con-
sump.
W.
Weight
Kg.
Height Length Width Height Length Width
2101270 180 3 70 51 43 85 60 85 250 36
2101271 260 4 104 51 43 122 60 85 330 47
2101272
2101273
500 5 134 65 53 151 76 95 330 78
* Maximum weight per shelf, 50Kg (evenly distributed)
EQUIPMENT DESCRIPTION
MEDILOW cooling cabinets are designed to work with adjustable
temperatures from +2ºC up to +40ºC, with a stability of ±1,5ºC.
They are specially appropriated for BOD
5D
determination at
20ºC, enzymatic measurement at 25ºC, perservation of sample,
incubator, cosmetics, botanics, food, etc.
Epoxy-coated outer casing and strong ABS inner chamber-easily
cleaned.
Circulating fan inside the chamber, hermetic compressor group
without vibrations. Side hole for connections, probes, etc.
Height-adjustable front base supports. Lockable door, and it can
be opened from left or right.
Note: model 2101273 has the same features as model 2101272
but with glass door.
INSTALLATION
Place the equipment on a at, horizontal and level surface, trying
to leave a space of about 10 cms. at the back and on each side.
Avoid positioning the equipment in direct sunlight or exposed
to similar sources of heat. Poorly ventilated rooms are also
unsuitable.
The ventilation grille at the back of the equipment must NOT be
blocked not even change its position.
