Selectron CPU 723-T - CPU 72 x Extension Bus and Dimensions

CPU 72x
24.05.2019 page 4
1.2 Extension Bus and Dimensions
1.2.1 Extension Bus
On the right-hand side of the front of the units, there are connection plugs for the
MOBI bus, by means of which the extension modules are connected.
MOBI bus
Fig.01: MOBI bus: extension bus plug (view from front)
1.2.2 Dimensions
Fig.02: Dimensions CPU 72x
155
85
